NOKIA FWED 473136A

Frame Structure: The AMIA frame is 3U high. It can be installed in a standard 19 - inch rack and also supports stacking installation, which is convenient for flexible deployment. Internally, it contains a backplane for handling high - bandwidth connections between plugins, as well as fans and a rear backplane. The rear backplane is responsible for internal communication and DC power supply. Functional Configuration: It can support one or two Nokia AirScale Common (asik) plugins for transmission interfaces and centralized processing, and one to six Nokia AirScale Capacity (abil) plugins for baseband processing and providing optical interfaces for wireless devices. The minimum configuration is a sub - rack with one asik and one abil. This configuration method allows for flexible deployment according to different network requirements. Network Support: It supports 4G and 5G networks, as well as CPRI and ECPRI interfaces. In addition, it supports multiple standards such as GSM, WCDMA, FDD - LTE, TDD - LTE, LTE - A Pro, and 5G. It can realize the integrated deployment of multi - standard networks, reducing the complexity and cost of base station equipment. Architecture Support: It supports distributed RAN, centralized RAN, and cloud RAN architectures. It can be flexibly deployed according to different network planning and operation requirements, adapting to different network scenarios and service models. ​

The AirScale System Module simplifies  4G and 5G Single RAN deployments, streamlines multi-band sites and powers multi-site baseband hotels. ​

The Nokia 473096A ABIA AirScale Capacity is a cutting - edge mobile network equipment designed for telecommunications service providers. It is part of Nokia's AirScale radio access solution and offers exceptional capacity and scalability to support the ever - increasing demand for data traffic and mobile services. With a compact and modular design, the Nokia 473096A ABIA AirScale Capacity can be easily integrated into existing network infrastructure and expanded to meet future capacity requirements. It supports various wireless standards, including 5G, 4G/LTE, and 3G, and can operate in both standalone and network - sharing modes. The equipment features advanced MIMO (Multiple - Input, Multiple - Output) technology that allows it to transmit and receive data on multiple antennas simultaneously, increasing the network's capacity and efficiency. It also supports carrier aggregation, enabling it to combine multiple frequency bands to provide higher data rates and better network coverage. The Nokia 473096A ABIA AirScale Capacity is equipped with state - of - the - art security features, including authentication, encryption, and key management, ensuring the confidentiality and integrity of the network traffic. It also includes advanced network management tools that enable service providers to monitor and optimize network performance in real - time, ensuring a high - quality user experience. ​

Function and Application13: It is a key component of the base station system, which helps to expand the capacity of the base station, improve the processing ability of the system for multiple services, and meet the increasing demand for wireless communication services. It can be widely used in various scenarios such as urban and rural areas to provide reliable wireless network coverage. Technical Features13: It adopts a new flexi signal processing architecture and advanced switching architecture, which can realize efficient processing and transmission of signals. It is also equipped with an advanced second - generation Nokia ASIC for OBSAI/CPRI fronthaul links, which improves the efficiency and reliability of data transmission. In addition, it has advanced power management for ASIC, DSPs, network processors, and FPGAs, which helps to save energy and reduce operating costs. ​

The Nokia 472181A FSMF (Flexible System Module Fabric) is a cutting - edge network module and a crucial part of Nokia's AirScale base station family. It is designed to be the core of the base station system, playing a vital role in building robust and scalable mobile telecommunications infrastructure. This system module offers unmatched flexibility, supporting a wide range of network architectures such as GSM, WCDMA, LTE, and 5G, enabling seamless network evolution. It has high - speed data processing capabilities, which can efficiently manage multiple network traffic streams. With advanced synchronization features, it ensures precise timing across the network for reliable mobile services. Its modular design facilitates easy integration and scalability to meet the growing demands of the network. In addition, it has enhanced security features, including robust encryption and authentication, to protect sensitive data. It also incorporates advanced technologies such as edge computing, network slicing, and cloud - native architecture for long - term network optimization. ​

Base station equipment  FRGU 472956A.102 NOKIA FRGU for Nokia ​

The Nokia FXED 492924A is a FLEXI RF MODULE 6TX 1800. It belongs to Nokia's Flexi series and is suitable for the 1800MHz frequency band. With 6 transmit channels (6TX), it can provide efficient RF signal processing and transmission functions. It supports long - term network evolution and is one of the key components for realizing flexible and scalable wireless communication network deployment. ​

Nokia Mounting covers 470239A-FMCA Telecom Equipment Mounting Cover Front for BBU RRU ​
